Model |
ICA-HM351 |
Video Specification |
|
Image Sensor |
1/2.7" Progressive CMOS |
Lens |
4mm fixed lens with Fixed Iris |
Sensitivity |
0.5 Lux @ F1.4 |
View Angle |
H: 66 Degree |
Video Encoder |
H.264 / MPEG-4 / M-JPEG |
Rate Control |
CBR (Constant Bit Rate) / VBR (Variable Bit Rate) |
Video Resolution |
1920 x 1080 / 1280 x 720 / 640 x 360 / 320 x 180 / 160 x 90 |
Frame Rate |
Up to 30fps for all resolutions (2M Real-time) |
Image Control |
AE, AWB |
Image Sensor |
1/2.7" Progressive CMOS |
Lens |
4mm fixed lens with Fixed Iris |
Sensitivity |
0.5 Lux @ F1.4 |
Audio Specification |
|
Audio Codec |
RTSP: G.711 64kbps, G.726 32kbps |
Audio Streaming |
One-Way or Two-Way |
Microphone (Audio Input) |
External microphone input, Phone Jack |
Audio Output |
Adjustable audio output gain, Phone Jack |
Network and Configuration |
|
Network Interface |
1 x RJ-45 |
Network Standard |
IEEE 802.3 / IEEE 802.3u / IEEE 802.3af |
Network Protocol |
IPv4, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP |
Browser / Software |
Microsoft ® Internet Explorer 6.0 or later |
Motion Detection |
10 areas definable |
Environment Specification |
|
Power Requirement |
12V DC, 1A |
PoE |
IEEE 802.3af (PoE is for IP cam & IR LED only, Heater & fan require external adaptor) |
Dimension (W x D x H) |
141 x 310 x 120 mm |
Weight |
1335 g |
Power Consumption |
Max. 8W for camera and IR LEDs |
Protection Class |
IP-66 classification with Weather proof |
Operating Temperature |
-30 ~ 60 Degree C |
Operating Humidity |
0 ~ 95% (non-condensing) |
Emission |
CE, FCC |
