Model |
CAM4260 |
Image Sensor |
1/3" 1.3 megapixel progressive scan CMOS |
Lens |
2.8 - 11 mm varifocal lens, F1.4 |
SNR |
48dB |
WDR |
N/A |
Day/Night ICR |
Yes |
IR LED |
Yes (30M) |
Min. Illumination |
0 Lux (IR LEDs on) |
Iris Control |
Manual IRIS |
Shutter Time |
1/5 ~ 1/15,000 s |
Viewing Angle |
Diagonal: 122° ~35° |
Camera Angle |
Pan 0° ~340° |
Pan/Tilt/Zoom |
N/A |
Video Compression |
H.264/MPEG-4/MJPEG |
Resolution |
Up to 1280 x 1024 |
Frame Rate |
15 fps at SXGA (1280 x 1024) |
Video Stream |
Dual stream at H.264, MPEG-4, and MJPEG simultaneously |
Bit Rate |
64K ~ 6Mbps, VBR, CBR, controller frame rate and quality |
Video Control |
AGC (Auto Gain Control), AWB (Auto White Balance), AES (Auto Electronic Shutter), BLC (Back Light Compensation), image adjustment |
Intelligent Video |
Motion detection, tampering detection (blocked, redirected, defocused, or spray-painted) |
Video Jack |
N/A |
Built-in MIC |
N/A |
Audio Compression |
32KHz, ADPCM |
Audio Input |
3.5mm phone jack |
Audio Output |
3.5mm phone jack |
Alarm In |
2, terminal block |
Alarm Out |
1, terminal block |
Video Buffer |
5 second pre-alarm, 30 second post-alarm |
Event Action |
Send snapshot or video clip by FTP or email, record to NAS, record to local storage, trigger DO |
Supported Protocols |
IPv4, ARP, TCP, UDP, ICMP, DHCP, NTP, DDNS, SMTP, FTP, HTTP, CIFS, PPPoE, UPnP, RTP, RTSP, RTCP, 3GPP |
Ethernet |
10/100 Base-T / RJ45 |
Local Storage |
microSD/SDHC x 1 (Class 4/Class 6 only) |
RS-485 |
1 (2 pin on terminal block) |
USB |
N/A |
SDK |
Surveon SDK 2.0 |
OS |
Microsoft Windows XP/Vista/7 |
Browser |
Microsoft IE 6.0 or above |
Software |
Surveon VMS 2.4.1 |
emperature |
Operation:-10°C~ 50°C (14°~122°F) |
Humidity |
5 to 90% |
Power |
12VDC 1.5A;PoE (IEEE 802.3af) with Class 3 |
Power Consumption |
Max. 7.5W (w/o Heater ) |
Dimension (WxHxD) |
ø144mm x 116mm(H) |
Weight |
Net: 1,260g (2.78lb.) |
Certification |
Safety: LVD |
